KT-PNB01

- KT-PNB01 is a NB-IOT personnel management badge for personnel management and attendance inspection.    At the same time, data such as movement status and positioning trace are uploaded to the cloud in real time    to achieve visual personnel management.

- The product is small in size and easy to wear. NB-IOT solution based on the Internet of Things has better           cost. At the same time, it integrates a variety of ultra-low power intelligent sensors, and combines the low-       power self-research algorithm to make it last longer.

- Support global NB-IOT network, enabling global deployment.

1. Multiple Positioning

Base station positioning, GPS/Beidou, WIFI and other positioning technologies are integrated to grasp the real-time movement and location information of personnel; Supports electronic fencing, transportation trace planning and position offset alarm.

2. All-round Monitoring

Comprehensive monitoring of personnel, when there is a long stay and deviation from the work area, the system will automatically send an alarm response.

3. Flexible Configuration

Implement parameter configurations or upgrades in both local and remote ways. For example, the frequency of data sampling, reporting frequency and alarm threshold are not required for on-site operation and maintenance.

4. Data Storage

Staff dynamic trace and state information are stored in the cloud, supporting local data import and export.

5.  Data Visualization

Provide a visual management platform, so that managers know the location and status of employees anytime and anywhere, so as to reasonably allocate and manage work.

v General Parameters

Size：85*55*7mm

Weight：60g

Power：USB 5.0V power/Lithium battery

Working Temp：-20℃- 70℃

Battery Capacity：1000mAh(Default)

Endurance：10 days

Position Accuracy：

20m@WIFI； 5m@GPS/Beidou

v  Network Parameters

Mode：NB-IoT

Network：China Mobile/Unicom/Telecom

Frequency Band：B3/B5/B8

Speed：

Single-Tone:
Max 16.7 kbps （UL） /Max 25.5 kbps（DL）
Multi-Tone:
Max 158.5 kbps（UL）/Max 127 kbps（DL）
